Description
Product Information
OBDSTAR MP001 Set (MP001 Programmer+C4-01Host + W004/W005/ECU Bench Jumper).
Brand: OBDSTAR
| CPU | STM32F407VET6 |
| Connector | DC，OBD female，OBD male，DB9，DB25 |
| Input voltage | DC 12V/24V |
| Output voltage | 500mA |
| Weight | 260g |
| Working temperature | -10℃~55℃ |
| Device Size | 165*110*35mm |
Listed Package Contents
- 1pc x OBDSTAR MP001 Programmer
- 1pc x OBDSTAR C4-01 Host
- 1pc x W004 Read/Write soldering wire
- 1pc x W005 Read/Write soldering wire
- 1pc x W006 Clock frequency wire
- 1pc x OBDSTAR ECU Bench Jumper
Requirements & Application Notes
- 4. When read and write Chrysler GPEC2 ECM etc, MP001 does not require a 120ohm resistor between CAN H and CAN L wires, P003/P003+ does need it.
- Note: MP001 has P003+, P003, P002 functions. Different tablet device models require different configuration software.
- Recent OBDSTAR software update that requires MP001: OBDSTAR MS80/ MK70/ iScan Yamaha add Yamaha proximity 12-pin, 18-pin, support program via P003+ or MP001 Programmer.
